| Konu | Sayfa |
|---|
| Accessories & Options | 3 |
| Supplied Accessories. | 3 |
| Available Options. | 4 |
| Adjusting the Clock.. | 5 |
| Resetting the Microprocessor. | 5 |
| Installation and Interconnections | 6 |
| Antenna Considerations | 6 |
| About Coaxial Cable | 6 |
| Grounding. | 7 |
| Connection of Antenna and Power Cables. | 8 |
| Connection of Microphone and Headphone. | 9 |
| Key, Keyer, and Computer-Driven Keying Interconnections | 10 |
| VL-1000 Linear Amplifier Interconnections. | 11 |
| Interfacing to Other Linear Amplifiers. | 12 |
| Front Panel Controls & Switches | 13 |
| Display Indications....... | 18 |
| Rear Panel.. | 21 |
| MH-31A8J Microphone Switches.. | 23 |
| Optional FH-2 Switches..... | 24 |
| Basic Operation: Receiving on Amateur Bands...... | 25 |
| Operation on 60-Meter (5 MHz) Band (U.S. version only) | 28 |
| CLAR (Clarifier) Operation | 29 |
| LOCK | 30 |
| DIMMER | 30 |
| VFO COLOR | 30 |
| Band Stack Operation. | 31 |
| C.S (Custom Switch). | 31 |
| Convenience Features | 31 |
| SCOPE | 32 |
| More Frequency Navigation Techniques | 33 |
| Receiver Operation (Front End Block Diagram)... | 34 |
| ATT (ATTENUATOR). | 35 |
| Interference Rejection | 35 |
| IPO (Intercept Point Optimization) | 36 |
| IF Noise Blanker (NB) Operation | 37 |
| CONTOUR Control Operation | 38 |
| IF SHIFT Operation (SSB/CW/RTTY/PKT Modes). | 39 |
| WIDTH (IF DSP Bandwidth) Tuning (SSB/CW/ RTTY/DATA Modes) | 40 |
| NARROW (NAR) One-Touch IF Filter Selection... | 41 |
| IF NOTCH Filter Operation (SSB/CW/RTTY/ DATA/AM Modes). | 42 |
| Digital NOTCH Filter (DNF) Operation. | 43 |
| Digital Noise Reduction (DNR) Operation. | 43 |
| Tools for Comfortable and Effective Reception ...... | 44 |
| RF Gain | 44 |
| Audio Peak Filter | 45 |
| AGC (Automatic Gain Control) | 46 |
| Adjustable Receiver Audio Filter. | 47 |
| SSB/AM Mode Transmission | 48 |
| ATU Operation. | 50 |
| Using the Automatic Antenna Tuner. | 50 |
| About ATU Operation | 51 |
| PARAMETRIC MICROPHONE EQUALIZER (SSB/AM/FM MODE) | 52 |
| Enhancing Transmit Signal Quality. | 52 |
| Using the Speech Processor (SSB Mode) | 54 |
| Adjusting the SSB Transmitted Bandwidth (SSB Mode) | 55 |
| Voice Memory (SSB/AM/FM modes: Requires optional DVS-6 and FH-2)- | 56 |
| Transmitter Convenience Features | 56 |
| VOX (SSB/AM/FM Modes: Automatic TX/RX Switching using Voice Control) | 58 |
| MONITOR (SSB/AM/FM modes).. | 59 |
| Split-Frequency Operation | 60 |
| Setup for Straight Key (and Straight Key emulation) Operation.. | 61 |
| CW Mode Operation | 61 |
| Using the Built-in Electronic Keyer. | 62 |
| CW Spotting (Zero-Beating) | 65 |
| CW Convenience Features | 65 |
| CW Delay Time Setting | 66 |
| Contest Memory Keyer (Using the Optional FH-2 Remote Control Keypad) | 67 |
| Basic Operation | 72 |
| FM Mode Operation.... | 72 |
| Repeater Operation. | 73 |
| Tone Squelch Operation. | 74 |
| Memory Operation | 75 |
| Convenient Memory functions. | 75 |
| QMB (Quick Memory Bank) | 75 |
| Standard Memory Operation. | 76 |
| Memory Groups | 80 |
| Operation on Alaska Emergency Frequency: 5167.5 khz (U.S. Version Only).......... | 81 |
| VFO and Memory Scanning | 82 |
| VFO Scanning. | 82 |
| Memory Scan | 83 |
| PMS (Programmable Memory Scanning) ....... | 84 |
| RTTY (Radio Teletype Operation. | 85 |
| Example of Connecting RTTY Communications Device.. | 85 |
| DATA (PSK) Operation......... | 86 |
| Example of Data Communications Device | 86 |
| Menu Mode.. | 87 |
| Specifications | 91 |
